Mounting Style: |
Chassis Mounting |
Permissible Temp. With / Without load: |
-20 deg C to +85 Deg. C |
Permissible Temp. For Soldering: |
270 Deg. C for 5 seconds max. |
Panel Thickness(Max): |
N.A. |
Material: |
Polyamide G.F. . |
Insulation Resistance: |
100 M Ohms min. |
H. V. Break Down: |
2 KV/AC For 1 Minute . |
Current Carrying Parts: |
Brass, Tin Plated |
Contact Resistance (Initial): |
10 m Ohms max. |
Cap Design: |
N.A. |
App. Weight(Gm): |
3.3 |
Fuse Link Size: |
5 x 20 mm |
Rated Current / Voltage: |
6.3 Amps, 250V AC |
Terminals: |
Solder-type |
|
|
|
