Mounting Style: |
In-line (Hanging) |
Permissible Temp. With / Without load: |
-20 deg C to +85 Deg. C |
Permissible Temp. For Soldering: |
270 Deg. C for 5 seconds max. |
Panel Thickness(Max): |
N.A. |
Material: |
Polyamide G.F. / Polycarbonate |
Insulation Resistance: |
1000 M Ohms min. |
H. V. Break Down: |
2 KVAC For 1 Minute . |
Current Carrying Parts: |
Brass / Silver Plated |
Contact Resistance (Initial): |
20 m Ohms max. |
Cap Design: |
Screw-in |
Fuse Link Size: |
6.3 x 32 mm |
Rated Current / Voltage: |
12 Amps, 250V AC |
Terminals: |
Solder-type |
|
|
|
