CE |
Contact Arrangement: |
NO |
Permissible Temp For With/Without Load: |
-20 deg. C. to +85 deg. C . |
Permissible Temp For Soldering: |
270 deg. C. / 5sec. max . |
Operating Force: |
0.40 Kg. Max. |
Material: |
Engineering Thermoplastic |
Terminals: |
Solder-type / PCB-type |
Insulation Resistance(Min): |
100 M Ohms at 500 VDC |
H. V. Breakdown Test: |
1 KVAC For 1 Minute . |
Electrical Life: |
1,00,000 Cycles |
Current Carrying Parts: |
Terminals - Brass, Tin / Silver plated |
Contact Resistance(Max, Initial): |
10 m Ohms |
Contact & Voltage Rating: |
6A, 250V AC . |
Switch Type: |
Momentary |
Mechanical Life: |
1,00,000 Cycles |
|
|
|
|
