IEC Inlet |
| Mounting Arrangement: |
Screw Mounting |
| Voltage Rating: |
250 V AC |
| Current Rating: |
10 Amps. |
| Insulation Resistance: |
100 M Ohms Min. |
| Dielectric Strength: |
2KV AC for 1 Min. |
| Current Carying Parts (Contact): |
Brass, Nickel Plated |
| Current Carying Parts (Rear Tags): |
Brass, Tin Plated |
| Approximate Weight: |
12.7 gms. |
| Material Housing: |
Polyamide |
|
|
|
|
