No. of Poles: |
2Pole + Earth |
Reference Standards: |
DIN-43650, ISO-4400 |
Voltage: |
250V AC |
Material For Rubber Gasket: |
Nitril / Silicon |
Material Body: |
polyamide |
Insulation Resistance: |
100 M Ohms min. |
H. V. Breakdown Test: |
2 KV AC For 1 Minute . |
Terminals: |
Screw-type |
Current Rating: |
6 Amps. |
Permissible Temp. With/Without Load: |
-20 Deg. C to +85 Deg.C |
Current Caring Parts: |
Brass, Silver Plated |
Contact Resistance: |
20 m Ohms max. (Initial) |
Colours: |
Black / Gray |
Gland Size: |
PG-7 |
Mounting: |
Screw-type |
|
|
|
