IRS-1

IRS-104 - Rocker Switch, Panel Mount/Snap in, DPST, 4A, 250VAC, Illuminated. IRS-106 - Rocker Switch, Panel Mount/Snap in, DPST, 6A, 250VAC, Illuminated.
Contact Arrangement:	DPST
Mounting:	Panel, Snap-in type
Permissible Temp with / without Load:	-20 deg. C to + 85 deg. C
Permissible Temp For Soldering:	270 deg. C for 5 sec. max.
Terminal Style:	Solder-type / Fast-on 4.8 x 0.8
Product Weight:	4.6 gm .
Material For Housing:	Polyamide
Insulation Resistance (Min.):	100 M Ohms at 500 VDC
H. V. Breakdown Test:	1.5 KVAC For 1 Minute
Electrical Life:	10,000 Cycles
Material - Terminals:	Terminals-Brass / Copper, Silver plated
Contact Resistance(Max, Initial):	10 m Ohms
Colours Available For Rocker:	Rd / Gn / Am
Colours Available For Housing:	Bk
V/A Rating:	4 A, 250V AC
Type:	Illuminated
