With Indicator |
| No. of Poles: |
2 Pole + Earth |
| Reference Standards: |
DIN-43650, ISO-4400 |
| Voltage: |
12 VDC / 24VDC / 48 VDC / 110 VAC / 230 VAC |
| Product Weight: |
35.00 gms. |
| Material For Rubber Gasket: |
Nitril / Silicon |
| Material Body: |
Polyamide |
| Insulation Resistance: |
100 M Ohms min. |
| H. V. Breakdown Test: |
2KV AC For 1 Minute . |
| Terminals: |
Screw-type |
| Current Rating: |
10 Amps. . |
| Permissible Temp. With/Without Load: |
-20 Deg. C to +85 Deg.C |
| Current Caring Parts: |
Brass, Silver Plated . |
| Contact Resistance: |
20 m Ohms max. (Initial) |
| Colours: |
Transparent Body |
| Gland Size: |
PG-9 |
| Mounting: |
Screw-type |
|
|
|
