| Power Rating @70 deg.C : |
1/10W |
| Solderability: |
95% min. coverage |
| Life: |
+/- (1.0% + 0.05 Ohms) |
| Moisture Resistance : |
+/- (0.5% + 0.05 Ohms) |
| Resistance to Soldering Heat : |
+/- (1.0% + 0.05 Ohms) |
| High Temperature: |
+/- (1.0% + 0.05 Ohms) |
| Short Time Overload : |
+/- (1.0% + 0.05 Ohms) |
| Low Temperature Operation : |
+/- (0.05% + 0.05 Ohms) |
| Thermal Shock : |
+/- (0.05% + 0.05 Ohms) |
| Temperature Coefficient (by Type) : |
+/- 100 ppm/deg.C |
| Resistance Range 5%, E-24: |
1 Ohms ~ 10MOhms |
| Resistance Range 1%, E-96 : |
10 Ohms ~ 1MOhms |
| Max. overloaded volatge : |
100V |
| Max. working voltage: |
50V |
| Derated to 0 load at : |
+125 deg.C |
| Operating Temp. Range: |
-55 deg. C to +125 deg.C |
| Bending Strength : |
+/- (1.0% + 0.05 Ohms) |
