The WCR Series Thick Film chip Resisitors are manufactured by screening a metal glaze layer on a high grade ceramic body. The different resistance values are obtained by using different compositions of metal glaze. The end contacts are made to ensure optimum solderability. The resistive layer is then given a protective coating. The WCR series offer a wide range of power rating 1/20W to 1W are available in tolerance ranges of  1% and 5%. The miniature size, the excellent mechanical strength and electrical stability ensures reduced costs and enhances dependability. |
