- IP67
- High impact & heat resistant Polyamide Material
- Color coding as per Voltage
- Nickel plated Terminal with Double Screws
- Cable gland for external cable grip |
| IP Protection Type: |
IP67 |
| Weight (Approx): |
576 gms |
| Compliance Marking: |
CE |
| Reference Standard: |
IEC/EN 60309-1, IEC/EN 60309-2, UL-1686 |
| Material - Terminal Screw: |
MS, Zinc Plated |
| Material -Terminals: |
Brass, Nickel Plated |
| Material - Body: |
Polyamide |
| Permissible Temperature: |
-20 deg C TO +80 degC |
| Plug Angle: |
Straight |
| Earth Position: |
6h |
| Applicable Cable Size: |
10 - 16 Sq mm |
| Terminals: |
Screw-type |
| H.V Breakdown Test for 1 Min : |
2 KV AC |
| Insulation Resistance at 500VDC: |
100 M ohms min. |
| No. of Poles: |
3 Pin (2P+ E) |
| Current Rating: |
63A, 200-250 VAC, 50 - 60Hz |
|
|
|
