· IP67
· High impact & heat resistant Polyamide Material
· Color coding as per Voltage
· Nickel plated Terminal with Double Screws
· Cable gland for external cable grip |
| Reference Standard: |
IEC/EN 60309-1, IEC/EN 60309-2, UL-1686 |
| Compliance Marking: |
CE |
| IP Protection type: |
IP67 |
| Material - Terminal screws: |
MS, Zinc Plated |
| Material - Terminals: |
Brass, Nickel Plated |
| Material - Body: |
Polyamide |
| Permissible Temp.: |
-20 deg C TO +80 deg C |
| Plug Angle: |
Straight |
| Earth Position: |
6h |
| Applicable Cable Sizes: |
10 - 16 Sq mm |
| Terminals: |
Screw-type |
| H.V.Break Down Test (For 1-Minute): |
2 KV AC |
| Insulation Resistance At 500 V DC: |
100 M ohms min. |
| V/A Rating: |
63A, 200-250 VAC, 50 - 60Hz |
| Plug Type: |
63A, 3 Pin (2P+ E) |
| Weight - Approximately: |
576 gms |
|
|
|
